SPECIFICATIONS
|
Product Category: |
Fixed TV Wall Mount |
|
Rank: |
Standard |
|
Material: |
Steel,Plastic |
|
Metal Sheet Thickness: |
Bracket Arm THK=2mm cold-rolled sheet,Wall Plate THK=2mm cold-rolled sheet (Bracket Arm THK=0.079" cold-rolled sheet,Wall Plate THK=0.079" cold-rolled sheet) |
|
Surface Finish: |
Powder Coating |
|
Color: |
Matte Black |
|
Dimensions: |
954x625x30.5mm (37.6"x24.6"x1.2") |
|
Fit Screen Size: |
60"-100" |
|
Fit Curved TV: |
Yes |
|
Mounting Hole Pattern: |
VESA & Universal |
|
VESA Compatible: |
200x200,300x200,400x200,300x300,400x300,400x400,600x400,600x600,800x600,900x600 |
|
Max. Mounting Hole: |
900x600 |
|
Weight Capacity: |
75kg (165lbs) |
|
Strength Tested: |
3 Times Approved |
|
Profile: |
30.5mm (1.2") |
|
Screen Freely Tilting: |
No |
|
Installation: |
Solid Wall,Double Stud(406mm/450mm/600mm) |
|
Panel Type: |
Detachable Panel |
|
Wall Plate Type: |
Fixed Wall Plate |
|
Cable Management: |
No |
|
Anti-theft: |
No |
|
Bubble Level: |
Hook-on Bubble Level(Included in Components Package) |
|
Accessory Kit Package: |
Normal/Ziplock Polybag,Compartment Polybag |
